Performance Materials Electrical Insulation Data Sheets
JBC Technologies offers a selection of lightweight, synthetic electrical insulation and barrier materials engineered for use in industrial and consumer electronic equipment. Our precision die-cutting expertise is used by customers in a wide variety of industries from EV/automotive and industrial equipment to electronics & appliance manufacturers.
Browse our list of materials and manufacturers below and to learn more click on the product names to download a material data sheet.
DuPont™ Mylar® Polyester Film
Mylar® is a heat-resistant polyester film that combines dielectric strength with moisture resistance. When used as an insulation it is flexible and will not become brittle during normal use. Can be used as an electrical insulator over a wide range of temperatures, and resists most chemicals.
DuPont™ Nomex® 410
Nomex® 410, the original form of Nomex® paper, is widely used in a
majority of electrical equipment applications. It offers high inherent dielectric strength, mechanical toughness, flexibility and resilience. Available in 11 thicknesses ranging from 0.05 mm to 0.76 mm (2 mil to 30 mil).
ITW Formex® GK
Formex® GK is a flame retardant polypropylene barrier material engineered to provide superior electrical insulation in industrial and consumer electronic equipment. The insulating material is available in rolls and sheets and can be easily fabricated into a wide range of parts. Complies with UL 94 V-0, CSA, IEC, RoHS and WEEE and can be used in service temperature up to 115°C
Lydall® LyTherm® 550L
An easy-to-cut, lightweight utility paper processed from unwashed spun, high-purity alumina-silica fibers formed into a highly flexible sheet. Makes an excellent thermal and electrical insulator. Recommended for continuous use at temperatures up to 2300°F (1260°C) in applications where insulating efficiency is not critical.
Lydall® LyTherm® 970
A lightweight, binderless commercial-grade paper composed of a refractory material processed from washed, spun, high purity alumina-silica fibers formed into a highly flexible sheet. It is recommended for continuous use at temperatures up to 2300°F (1260°C) in applications where insulating efficiency and high strength are important and where off-gassing of organic binder cannot be tolerated.
Lydall® LyTherm® 1530
A lightweight, premium grade paper composed of a refractory material processed from highly washed, spun, high purity alumina-silica fibers formed into a flexible sheet. Formulated to minimize unfiberized particles, LyTherm 1530 paper offers an extremely low thermal conductivity and a dust-free surface. Recommended for continuous use at temperature up to 2300°F (1260°C) in applications requiring high strength, resiliency, and excellent thermal properties.
3M™ 1350F Tape (Flame-Retardant Tape with Polyester Film and Acrylic Pressure-Sensitive Adhesive)
An electrical insulating polyester film tape which meets the flame retardant requirements of UL 510. It consists of materials that are represented in many UL Recognized Insulation Systems and has a UL 130˚C temperature rating. It also offers excellent flagging and solvent resistance; good wet grab; smooth, even unwind and is suitable for use on automated equipment. Especially suited for applications such as wrapping coils, capacitors, wire harnesses, transformers, shaded pole motors and fractional horsepower motors.
For more information Contact a JBC representative
While these downloadable material data sheets can get you started, they are just a portion of what JBC works with to meet our customers' needs. JBC converts a vast range of high performance gasketing, sealing, and shielding materials. With thousands of materials in stock, we offer fast turnaround while maintaining competitive pricing.
