Pressure-Sensitive Adhesives Thin Bonding Tapes Material Data Sheets
JBC converts a wide range of high performance materials - including these thin bonding tapes - for gasketing, sealing, and shielding applications.
Thin bonding tapes are simply a special type of PSA tape - normally double-coated or transfer tapes - that are designed for use in applications where you want the adhesive tape as thin as possible without sacrificing bonding performance. Thin Bonding Tapes often have a thickness of 10 mil (0.254mm) or less and are highly conformable making them ideal for use on complex surface geometries.
Want to learn more? Browse our selection of thin bonding tapes below and download their technical data sheets for your reference.
3M™ VHB™ Adhesive Transfer Tape F9460PC
3M VHB Adhesive Transfer Tape F9460PC is a thin, double sided tape capable of conforming to a wide variety of applications. Designed with 2.0 mil 3M High Performance Acrylic Adhesive 100MP, VHB Adhesive Transfer Tape F9460PC establishes exceptional holding power and long-lasting adhesion for fast, strong results.
3M™ VHB™ Adhesive Transfer Tape F9469PC
3M VHB Adhesive Transfer Tape F9469PC utilizes the 3M High Performance Acrylic Adhesive 100MP, which has excellent long term holding power with much higher adhesion strength than typical pressure sensitive adhesive systems. This 3M VHB Adhesive Transfer Tape is transparent and is ideal for use in many interior and exterior industrial applications to replace rivets, spot welds, liquid adhesives, and other permanent fasteners.
3M™ Adhesive Transfer Tape 966
3M Adhesive Transfer Tape 966 leverages the power of 3M High Temperature Acrylic Adhesive 100 to produce an excellent high temperature, high strength and chemical resistant bond suitable to the demands of aerospace, automotive and electronics markets. It provides low outgassing properties necessary to deliver optimal performance in demanding applications.
3M™ Ultra High Temperature Double Coated Tape 9077
3M Ultra High-Temperature Double-Coated Tape 9077 is a 2.0 mil clear double-coated adhesive tape designed for continued adhesion in high-temperature environments up to 500°F/260°C. It features a 2 mil layer of 3M Ultra High Temperature Acrylic Adhesive 100HT, excellent for use in FPC attachment and for HSE metals. A 3.6 mil heat-resistant non-woven liner adds stability for die-cutting and converting.
3M™ Adhesive Transfer Tape 468MP
3M Adhesive Transfer Tape 468MP features 5.2 mils of 3M High Performance Acrylic Adhesive 200MP for splicing and laminating procedures using metals and HSE plastics. The thicker caliper adds wet-out capability for surfaces where adhesion may be compromised by slight textures or irregularities. 4.2 mil, 58 lb. polycoated kraft paper liner, is excellent for rotary processing of graphic and die cut parts. This adhesive transfer tape also resists solvents, humidity and moisture, as well as heat up to 400°F / 204°C for short periods.
3M™ Membrane Switch Spacer 7956MP
3M Membrane Switch Spacer 7956MP features 3M's High Performance Acrylic Adhesive 200MP and is ideal for the stresses of switch actuation over long periods. The double-coated adhesive is formulated for excellent shear strength and forms a durable bond with plastics and other smooth surfaces with less oozing at the edges. This allows for easier slitting and die-cutting, faster part processing and minimal waste. The adhesive is applied at 2.0 mils to each side of a 2.0 mil polyester film carrier which adds structural strength.
Double 4.2 mil 58 lb. polycoated kraft (PCK) paper lay-flat liners are designed to cover adhesive consistently for full bonding performance after application. Liners resist curling, tunneling and buckling, increase dimensional stability and hold up even under high humidity for efficient storage and processing. Liner design also enables improved rotary die-cutting at high speeds, as well as improved sheet processing.
3M™ Adhesive Transfer Tape 467MP
3M Adhesive Transfer Tape 467MP is designed with a 2.3 mil thick adhesive for applications such as splicing and laminating procedures using metals and HSE plastics. This high-performance adhesive delivers excellent shear strength to resist slippage and edge lifting. It is mounted on 58 lb. polycoated kraft paper liner which virtually eliminates curling, rippling and buckling and provides efficient release.
3M™ Double Coated Tape 92015
3M Double-Coated Tape 92015 is coated with 3M Adhesive 200MP and offers outstanding adhesion on metal and other high surface energy plastics. It performs well after exposure to humidity and hot/cold temperatures up to 400°F/204°C, or 300°F/149°C in Double Coated constructions. Delivers excellent shear strength to resist slippage and edge lifting and offers quick stick to a wide variety of substrates. This tape is a double coated version of 3M Adhesive Transfer Tape 468MP.
3M™ Double Coated Tape 9832HL
The heavy 83 lb. polycoated kraft paper liner on 3M Double Coated Tape 9832HL improves handling and is ideal for die-cutting and laminating applications. An alternative to glue, screws and rivets, this double sided tape is often used for a variety of applications, including foam lamination and gasket attachment in general industrial applications.
3M™ Adhesive Transfer Tape 6035PC
3M Adhesive Transfer Tape 6035PC features 5.0 mils (.13 mm) of 3M™ Adhesive 300MP coated on a 4.2 mils (.10 mm), 58 lb. polycoated kraft paper liner. The adhesive is specifically designed to be low fogging, and provides a strong bond on many surfaces, including plastics, wood, foam, fabric and metal. This adhesive transfer tape meets automotive specifications, making it ideal for use on interior fabrics and panels.
3M™ Adhesive Transfer Tape 9775WL
3M Adhesive Transfer Tape 9775WL is designed for permanently bonding plastics, foams, wood and textiles. The adhesive easily flows into crevices and voids without the addition of heat. Minimal pressure is required. This transfer tape features 3M Adhesive 300MP, a high tack acrylic that delivers good initial bond and full adhesion within 48 - 72 hours.
3M™ Double Coated Tape 93015LE
3M Double Coated Tape 93015LE offers good chemical, humidity and moisture resistance, as well as performance across a wide temperature range (from -40°F/-40°C to 300°F/148°C). The bond strength increases as a function of time and temperature, and has very high initial adhesion. Supplied on a tan 58 lb. polycoated kraft paper liner ideal for die-cutting and converting applications. Part of the 3M™ High Strength Acrylic Adhesive 300LSE family, this tape meets UL746C (reference file QOQW2.MH17478).
3M™ Double Coated Tape 93010LE
3M Double Coated Tape 93010LE uses 3M™ High Strength Acrylic Adhesive 300LSE and provides a high bond strength to most surfaces, including many low surface energy (LSE) plastics such as polypropylene and powder coated paints. The 0.044mm (1.7 mil) thick acrylic adhesive also provides excellent adhesion to surfaces contaminated with oil typically used with machine parts. Good chemical, humidity and moisture resistance, and performance across a wide temperature range (from -40ºF/-40ºC to 300ºF/148ºC). 58 lb. polycoated kraft paper liner ideal for die-cutting and converting applications. Manufactured using a solventless process, 3M™ Double Coated Tape 93010LE meets UL746C (reference file QOQW2.MH17478).
3M™ Double Coated Tape 9495LE
3M Double Coated Tape 9495LE is a clear tape that features a 6.7 mil thick layer of 3M™ Laminating Adhesive 300LSE. It provides high bond strength to most surfaces, including many low surface energy (LSE) plastics such as polypropylene and powder coated paints. Use on low surface energy surfaces and as plastic extrusion attachment. It also improves handling and ease of die-cutting.
3M™ Double Coated Tape 93020LE
3M Double Coated Tape 93020LE uses 3M™ High Strength Acrylic Adhesive 300LSE is a market-proven, double coated transfer tape with good anti-lifting properties. This tape bonds well to similar and dissimilar materials including, metals, most plastics, glass, papers and painted surfaces.. The 0.094mm (3.7 mil) thick acrylic adhesive also provides excellent adhesion to surfaces contaminated with oil typically used with machine parts. Good chemical, humidity and moisture resistance, and performance across a wide temperature range (from -40ºF/-40ºC to 300ºF/148ºC). 58 lb. polycoated kraft paper liner ideal for die-cutting and converting applications. Manufactured using a solventless process, 3M™ Double Coated Tape 93010LE meets UL746C.
3M™ Adhesive Transfer Tape 9471LE
3M Adhesive Transfer Tape 9471LE is a versatile, market proven, 2 mil (0.05 mm) transfer tape on a release liner. Featuring 3M™ 300LSE acrylic adhesive, this tape has a long and proven history of reliably bonding a wide variety of similar and dissimilar materials such as metals, most plastics, glass, papers and painted surfaces. Supplied on a 58 lb. polycoated kraft paper liner ideal for die-cutting and converting applications. Meets UL 969
