Medical-Grade Tapes & Adhesives Technical Data Sheets

Need help choosing the right medical tape or adhesive material for your next die-cutting project? You've come to the right place. We've partnered with the world's leading manufacturers so we're able to offer our customers the latest technologies in specialty pressure sensitive tapes and adhesives. Click on any of the material names below to view the manufacturer's product information sheet.



Single-Coated Tapes

Polyken® 2203R Flexible Film Tape

arrow right

A single-coated medical flexible film comprised of a 3 mil matte finish clear polyethylene film backing. a non-sensitizing medical-grade acrylic adhesive and 60lb kraft backing with a silicone release treatment on one side. Common uses for this medical-grade flexible film tape include medical device attachment, drape to patient attachment, and incise drape for surgical incision.

Polyken® 3570A Non-Woven Single-Coated Tape

arrow right

A non-woven single-coated medical tape comprised of a 2.4 oz/sy white spunlace polyester non-woven backing, a long-term wear medical-grade acrylic adhesive and 80lb super-calendared kraft, silicone release liner treated on both sides. Common uses for this medical-grade flexible tape include wearable device applications including CGM and medication delivery systems, electrodes, and for medical device assembly.

Polyken® 3585A Single-Coated Foam Tape

arrow right

A single-coated foam tape comprised of a 1/16" white, crosslinked polyethylene foam backing, highly moisture-resistant, extended-wear acrylic (M110) adhesive and 74lb bleached polycoated kraft, silicone liner treated on one side. Common uses for this flexible foam tape include AED defibrillator pads, transdermal delivery systems and ECG, EKG, and TENS electrodes.

Polyken® 3614B Non-Woven Single-Coated Tape

arrow right

A non-woven single-coated tape comprised of a 1.3 oz/sy white spunlace polyester nonwoven backing, non-sensitizing medical-grade acrylic (M109) adhesive and 72lb white polycoated kraft, silicone liner treated on one side. Common uses for this non-woven single-coated tape include wound coverings, island dressings, and electrode attachment.

Polyken® 3614C Non-Woven Single-Coated Tape

arrow right

A non-woven single-coated tape comprised of a 1.3 oz/sy white spunlace polyester nonwoven backing, non-sensitizing medical-grade acrylic (M102) adhesive and 72lb white polycoated kraft, silicone liner treated on one side. Common uses for this non-woven single-coated tape include wound coverings, island dressings, and electrode attachment.

Polyken® 3621A Non-Woven Single-Coated Tape

arrow right

A non-woven single-coated tape comprised of a 2.4 oz/sy white polyurethane non-woven fabric backing, long-term wear medical-grade acrylic (M102) adhesive and 80lb super-calendared kraft, silicone release liner treated on both sides. Common uses for this non-woven single-coated tape include wearable devices for remote patient monitoring, medical device and component assembly, and electrode attachment (EKG, ECG, etc.).

Double-Coated Tapes

Adchem Logo

Polyken® 1731D Double Coated Tape

arrow right

A medical-grade double-coated tape comprised of a 76lb polycoated bleached kraft,
silicone treated on both sides liner, non-sensitizing acrylic (M109) liner-side adhesive, 0.5 mil polyester film carrier and non-sensitizing acrylic (M109) air-side adhesive. Common uses for this double-coated tape include surgical drape application and assembly, medical device assembly and attachment.

Polyken® 3428M Double-Coated Film Tape

arrow right

A medical-grade double-coated film tape comprised of a 80lb bleached silicone release liner treated on both sides, non-irritating acrylic (M119) liner-side adhesive, 1 mil polyurethane film carrier and non-irritating acrylic (M119) air-side adhesive. Common uses for this double-coated film tape include toupee attachment, surgical drape application and assembly, and medical device assembly and attachment.

Polyken® 9254M Medical Double-Coated Tape

arrow right

A medical-grade double-coated tape comprised of a 74lb polycoated kraft liner (available in 55lb), medical-grade acrylic (M129) liner-side adhesive, 0.5 mil PET film carrier and medical-grade acrylic (M129) air-side adhesive. Common uses for this double-coated tape include lamination and bonding to papers, rigid and flexible plastics, non-wovens, and foam as well as medical device attachment and assembly.

Transfer Tapes

Polyken® 3426A Transfer Adhesive

arrow right

A transfer adhesive comprised of a rubber-based (M104) adhesive on a 60lb bleached kraft liner with a double-sided silicone differential release liner. Common uses for this adhesive transfer tape include mounting and laminating electronic components and attachment of patient monitoring devices (BGM, pulsoximetry).

Polyken® 9728 Medical Transfer Tape

arrow right

A medical transfer tape comprised of a 2mil non-irritating (M129) acrylic adhesive on a 4mil 80lb white densified kraft liner. Common uses for this adhesive transfer tape include room temperature bonding to films, foams and fabrics. This transfer tape also has excellent adhesion to skin.

Polyken® 9730 Medical Transfer Tape

arrow right

A medical transfer tape comprised of a 3mil non-irritating (M129) acrylic adhesive on a 4mil 80lb white densified kraft liner. Common uses for this adhesive transfer tape include room temperature bonding to films, foams and fabrics. This transfer tape also has excellent adhesion to skin.

For more information Contact a JBC representative

While these downloadable material data sheets are a good start, they're really just the beginning. JBC converts a vast array of high-performance gasketing, sealing, and shielding materials and with thousands of materials in stock and ready to convert, we offer fast turnaround along with competitive pricing.
